Description

Basic Info.
Model NO. CST200S
Customized Customized
Certification CE, ISO, RoHS
Material Stainless Steel
Type Incubator
Voltage 380V
Temperature Range -70~+150
Specification 150L
Trademark ATEC
Origin China
HS Code 8479899990
Packaging & Delivery
Package Size 1000.00cm * 1000.00cm * 1000.00cm Package Gross Weight 1000.000kg
Product Description
Temperature Shock Test Chamber
Today, the automotive industry accelerates electronic multi-functions. According to this trend, safety standards such as ISO26262 and IEC61508 require high environmental stress that is generated by thermal shock chambers for higher reliability of vehicle equipment.

ModelCST200S
Internal dimension (W*D*H)600*600*550mm
External dimension (W*D*H)1600*2500*2500mm
Heating ZoneTemperature Range
H type: +50ºC ~ +150ºC / M type: +50ºC ~ +150ºC / H type: +50ºC ~ +125ºC
Preheat Temperature(max)200ºC
Heating TimeRT~ +200ºC H type:≤30min / M type:≤40min / L type:≤50min
Cooling ZoneTemperature RangeH type:-65ºC / M type:-55ºC / L type:-40ºC
Preheat Temperature(max)-75ºC
Cooling TimeRT~ -70ºC H type:≤40min / M type:≤50min / L type:≤60min
Transfer time≤10s
Temperature recovery time≤5min
Optional:temperature function-65ºC ~ +150ºC
Heating speed4ºC/min (average in no load at -55ºC ~ +85ºC)
Cooling speed2ºC/min (average in no load at -55ºC ~ +85ºC)
Load (steel)10kg
Temperature fluctuation±0.5ºC
Temperature uniformity±2ºC
Internal chamber materialSUS304 stainless steel(1.5mm), fully welded seam, vapor impermeable.
External chamber materialSpay steel(1.5mm)
Cooling methodWater cooling
ControllerLCD touch screen (internet function optional)
CompressorTecumseh compressor
Inspection window450*450mm
Testing hole1 *Ø50mm
Stainless Steel Shelf( 2pcs)Bearing 15kg/pc

Water-cooled type need installation conditions:The customer must prepare water pipe and water tower (located outside) accordingly.The water must be pure, or it will block the pipes and result in some maintenance trouble with time going.It's often applied to large system with the features of better heat dissipation, longer service time, low noise but slightly higher price if count the fee of water tower and water pipes.

3-Zone Temperature Shock Test Chamber

3-Zone Temperature Shock Test Chamber

3-Zone Temperature Shock Test Chamber

3-Zone Temperature Shock Test Chamber

3-Zone Temperature Shock Test Chamber
